Continuity
Diode Test
Capacitance
*
1
. Accuracy with film capacitor or better
Using Mode
Frequency and Duty Cycle
25
Temperature (Model 703 only)
* This specification is effective at the ambient temperature of 23 C (73.4 F) only.
Frequency Counter Sensitivity
Burden Voltage ( A, mA, µA)
24
Remark
Accuracy
701 703
Minimum frequency :
0.5 Hz
Sensitivity :
5 Hz–1 MHz, > 250 mV
1 MHz–10 MHz, > 350 mV
0.001 Hz
0.01 Hz
0.05 % + 3
0.05 % + 3
0.1 Hz
1 Hz
10 Hz
Range
5 Hz
50 Hz
500 Hz
5 kHz
50 kHz
500 kHz
100 Hz
5 MHz
1 kHz
10 MHz
10 kHz
0.1%
0.5 Hz to 500 kHz (pulse width > 2 µsec.)
(0.1% + 0.05% per kHz + 1 count) for 5 V input (Logic signals only)
0.1% to
99.9%
Resolution
Function Burden Voltage (typical)
mA / µA
Range
400 µA
4000 µA
40 mA
400 mA
4 A
10 A
150 µV / µA
150 µV / µA
3.3 mV / mA
3.3 mV / mA
0.03 V / A
0.03 V / A
10 A
Range Accuracy Open Circuit Voltage
4V 2%
Test Current
(Typical)
0.25 mA < 1.5 V dc
Audible threshold : the beeper sounds if the measured resistance is lower than
10 , and turns off when greater than about 60 .
Response time : < 1 msec.
Range
701 703
Accuracy *
1
2.5 % + 10 2.5 % + 10
40 nF 10 pF
400 nF 100 pF
4 µF 1 nF
40 µF 10 nF
100 µF 100 nF
Resolution
Range Accuracy
- 40 C to -10 C
(-40 F to 14 F)
Resolution
1 C
1 F
3% ± 5 C
(3% ± 5 F)
- 10 C to 400 C
(14 F to 752 F)
1 C
1 F
1% ± 3 C
(1% ± 3 F)
400 C to 1300 C
(752 F to 2372 F)
1 C
1 F
3% of reading
(3% of reading)
Range
Minimum Sensitivity ( RMS Sine Wave )
V
(4 V to 1000 V)
500 mV
40 Hz to 10 kHz 40 Hz to 20 kHz
500 mV
µA
(400 µA to 4 mA)
> 15 % F.S. of AC range Not Specified
mA
(40 mA to 400 mA)
> 15 % F.S. of AC range Not Specified
A
(4.0 A to 10 A)
> 45 % F.S. of AC range Not Specified
*
