SOURCES LIKE SMALL HAND-HELD RADIO
TR ANSCEIVERS, FIXED STA TION RA DIO
AND TELEVISION TRANSMITTERS, VEHICLE
RA DIO TR ANSM ITTERS AND CEL LULAR
PHONES GENERATE ELECT ROMAGNETIC
RADIATION THAT MAY INDUCE VOLTAGES
IN THE TEST LEADS OF THE MULTIMETER.
IN SUCH CASES THE ACCURA CY OF THE
MULT IMETER C ANNOT BE GUARAN TEED
DUE TO PHYSICAL REASONS.
W A R N I N G !
Basic Specifications
DC Voltage : 0 to 1000 V
AC Voltage
703 (True RMS) : 15 mV to 1000 V (@ 40 Hz to 20 kHz)
701 : 0 to 1000 V (@ 40 Hz to 400 Hz)
Basic Accuracy : DC voltage – 0.5%
AC voltage – 0.75%
DC Current : 0 to 10 A (20 A for 30 seconds)
AC Current
703 (True RMS) : 20 µA to 10 A (20 A for 30 seconds)
701 : 0 to 10 A (20 A for 30 seconds)
Resistance : 0 to 40 M
Capacitance : 0.01 nF to 100 µF
Frequency : 0.5 Hz to 10 MHz
Duty Cycle : 0.1 % to 99.9 % for 0.5 Hz to 500 kHz
(pulse width > 2 µsec.)
Diode Test : 2.5 V
Continuity Check : Beep at Approx. < 10 (response time < 1 ms)
Temperature (703 only): –40 C to 1300 C (–40 F to 2372 F)
1. Safety Information 2
2. Electromagnetic Compatibility (EMC) 3
3. Controls and Indicators 4
4. Rotary Switch and Pushbutton Overview 7
5. Meter Operation 9
6. Maintenance 19
7. Specifications 20
Limited Warranty & Limitation of Liability
Warning
Read
Safety Information” before using this Meter.
1
CONTENTS
