FingerTec TA200 Plus - Communications

17
TCP/IP PORT
POWER ADAPTER
PORT
RS484 PORT
2. RS485 Network Connection
1. RS485 Single Connection
RX+
RX-
RS232/ RS485
Data Converter
RX+
RX-
RS232/ RS485
Data Converter
RS232 PORT
RS232/RS485 SERIAL
CABLE PORT
AC100C MODEL & TA100C MODEL
USB PORT
TA200 PLUS MODEL
TCP/IP PORT
POWER
ADAPTER PORT
USB PORT
CONTENTS
Communications
Connection points for power and communication are available on top of the terminals.
Refer to the following diagrams for the terminals you require.
