Fini AIBOSS - Features Overview; Product Specifications Summary

10
FEATURES
PRODUCT SPECIFICATIONS
Running Horsepower ................................................ 1.5 HP
Air Tank Capacity ..................................................... 1.2 gal.
Air Pressure ....................................................135 PSI max.
Air Delivery ......................................... 1.7 SCFM @ 90 PSI
Lubrication .............................................................. Oil-Free
Gauges ....................................................... 1.5 in. diameter
Input................................. 120 V, 60 Hz, AC only, 9.5 Amps
Net Weight (compressor only) ................................19.9 lbs.
Fig. 2
PRESSURE
REGULATOR
KNOB
REGULATOR
PRESSURE
GAUGE
TANK
PRESSURE
GAUGE
QUICK
COUPLER
DRAIN
VALVE
TANK
SAFETY
VALVE
HANDLE
MANUAL
ON/OFF
SWITCH
INFLATION HOSE
WITH THUMB-LOCK
CONNECTOR
STORAGE
BOX FOR
ACCESSORIES
HOSE STORAGE
STRAP
25’ PVC
HOSE
