06
Schritt / Step 2
Position Bezeichnung Description: Abmessung: Menge/
Dimension: Quantity
-1 Rahmen senkrecht Vertical frame 1
-3 Sitzrahmen Seat base frame 1
-6S Sechskantschraube Hex head screw 3/8“x1“ 1
-15S Sechskantschraube Hex head screw 3/8“x4 1/4“ 2
-24S Unterlegscheibe Wascher Ø3/8“ 5
-28S Mutter, selbstsichernd Safety nut 3/8“ 2
