05
3.1 Montageschritte / Assembly steps
Schritt / Step 1
Position Bezeichnung Description: Abmessung: Menge/
Dimension: Quantity
-1 Rahmen, senkrecht Vertical frame 1
-2 Rahmen, hinten Rear base 1
-11S Sechskantschraube Hex head screw 3/8“x3“ 2
-24S Unterlegscheibe Washer Ø3/8“ 4
-28S Mutter, selbstsichernd Safety nut 3/8“-16UNC-11T 2
