DESCRIPTION
CONNECTIONS TO INSTRUMENTS
The new FLS M9.02 is a powerful ow monitor designed to convert the
frequency signal of FLS ow sensors into a ow rate. M9.02 is equipped with
a wide full graphic display 4” which shows measured values clearly and a
lot of other useful information. Moreover, due to a multicolor display plus a
powerful backlight, measurement status can be determined easily from afar
also. A tutorial software guarantees a mistake-proof and fast set up of every
parameters. Calibration can be performed just xing installation features or
using a reference value through a new “in-line calibration”.
A 4-20mA output is available to remote ow rate to a external device.
A proper combination of digital outputs allows customized setups for any
process to be controlled.
F3.00 F3.20 F6.30 F3.10 F3.05 F6.60 F6.61 F111
M9.02 x x - X - X X X
ULF F3.80
pH/
ORP200
pH/
ORP400
pH/
ORP600
C150/
200
C100/
C300
C6.30
M9.02 X X - - - - - -
TECHNICAL DATA
General
Associated sensors: FLS hall effect ow sensors with frequency output or
FLS F6.60 ow magmeters
• Materials:
- Case: ABS
- Display window: PC
- Panel & Wall gasket: silicone rubber
- Keypad: 5-button silicone rubber
• Display:
- LC full graphic display
- Backlight version: 3-colors
- Backlight activation: User adjustable with 5 levels of timing
- Update rate: 1 second
- Enclosure: IP65 front
• Flow input range (frequency): 0÷1500Hz
• Flow input accuracy (frequency): 0,5%
