Part Number 18160, F, 06/29/2021
Installation
Installing the Mounting Base
• Mounting Base should be installed vertically when installing CO Alarm on a wall.
• Use appropriate length #6, Pan Head screws to secure Mounting Base.
• Do not over-tighten.
• Drill appropriate size hole (0.38” (9.5mm) Max) for wired models to accommodate the
wires. If using a connector on the wires, a larger hole may be needed. Offset the hole
to the side of the Mounting Base with the wire slot, as shown.
