Fireboy- Xintex CMD6-MDR-B - Specifications

8
Part Number 18160, F, 06/29/2021
Specifications
System Specifications (CMD6-MB & CMD6-MB-B)
Operating/Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Alarm Points: Time Weighted Average (TWA)
Alarm Horn: ≈ 85dB @3.05M
Dimensions: 3.5” (89mm) x 3.5” (89mm) x 1.25” (32mm)
Housing Material: Polylac PA-765(ABS-FR)
System Specifications (CMD6-MBR & CMD6-MBR-B)
Operating/Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Alarm Points: Time Weighted Average (TWA)
Alarm Horn: ≈ 85dB @3.05M
Relay Output: 1A Max, 220V DC Max
Dimensions: 3.5” (89mm) x 3.5” (89mm) x 1.25” (32mm)
Housing Material: Polylac PA-765(ABS-FR)
System Specifications (CMD6-MD & CMD6-MD-B)
Operating Voltage: 12 or 24V DC
Maximum Voltage Range: 9-32V DC
Nominal Current Draw -40°F (-40°C) to 158°F (70°C): 6mA
Maximum Current Draw -40°F (-40°C) to 158°F (70°C): 38mA, 32V DC
Operating/Storage Temperature: -22°F (-30°C) to 158°F (70°C)
Alarm Points: Time Weighted Average (TWA)
Alarm Horn: ≈ 85dB @3.05M
Dimensions: 3.5” (89mm) x 3.5” (89mm) x 1.25” (32mm)
Housing Material: Polylac PA-765(ABS-FR)
System Specifications (CMD6-MDR & CMD6-MDR-B)
Operating Voltage: 12 or 24V DC
Maximum Voltage Range: 9-32V DC
Nominal Current Draw -40°F (-40°C) to 158°F (70°C): 6mA
Maximum Current Draw -40°F (-40°C) to 158°F (70°C): 38mA, 32V DC
Operating/Storage Temperature: -22°F (-30°C) to 158°F (70°C)
Alarm Points: Time Weighted Average (TWA)
Alarm Horn: ≈ 85dB @3.05M
Relay Output: 1A Max, 220V DC Max
Dimensions: 3.5” (89mm) x 3.5” (89mm) x 1.25” (32mm)
Housing Material: Polylac PA-765(ABS-FR)
Alarm Points
70 ppm
60-240 minutes
150 ppm
10-50 minutes
400 ppm
4-15 minutes
< 40 ppm
Alarm Reset
