Hot Water Series
4.4 System Diagram
Heating Mode
Water inlet
Water inlet
Water outlet
Water outlet
Defrosting Mode
High pressure switch
High pressure switch
Low pressure switch
Low pressure switch
4 way valve
4 way valve
Suction accumulator
Suction accumulator
Compressor
Compressor
Condenser
(fin-tube)
(fin-tube)
Evaporator
Throttling
element
Evaporator
(Tube in shell)
Condenser
(Tube in shell)
8
Throttling
element
