Firefox ME Series - Right Hand Side

OGF - ME Series
OPEN GAS FIREBOX SPECIFICATIONS
FRONT
TOP
RIGHT HAND SIDE
A
F
C
D
B
E
FLUE
SPIGOT
FLUE
SPIGOT
FAN
FAN
FAN
SWITCH
POWER
SUPPLY
POWER
SUPPLY
GAS PIPE
INLET
GAS PIPE
INLET
C
FLUE
SPIGOT
35
140
115
75
A
75
OGF - 27/ME
OGF - 30/ME
OGF - 35/ME
GFG 2.7
GFG 3.0
GFG 3.5
GAS INPUT
36 - 35 Mj Hr
41 - 40 Mj Hr
52 - 50 Mj Hr
FIREBOX
MODEL
FIREBOX DIMENSIONS
A B C D E F
720 655 370 160 620 603
780 690 390 155 680 638
900 725 405 155 800 673
178
(7”)
229
(9”)
203
(8”)
254
(10”)
229
(9”)
280
(11”)
}
}
}
APPROPRIATE GAS
FIREGRATE ‘GFG’
FLUE
INNER/OUTER
For installation and
commisioning procedure of
the Gas Firegrate/Burner
‘GFG’ refer to seperate
instructions entitled;
INSTALLATION & OPERATING
INSTRUCTIONS ‘GFG’ Series
FIREGRATES.
NG LP
OGF/27 (ME & ZC) Series
FIREFOX
MODEL
FIREBOX DIMENSIONS
ABCDEF
FLUE
INNER/OUTER
OGF - 27/ZC
OGF - 27/ME
175 225
(7”) (9”)
175 225
(7”) (9”)
720 640 400 160 680 630 }
720 640 370 160 620 605
2
