SERVICE 5-6 Manual 0-2846
B. Fuse Replacement
1. Remove the unit cover per paragraph "A" above.
2. Locate the internal fuse on the left side of the center
chassis.
3. Replace the fuse. Refer to Section 6 for replacement
fuse catalog number.
4. Reinstall the cover per paragraph "A" above.
A-02957
Fuse Location
Figure 5-4 Internal Fuse Location
This completes the service procedures.
