Manual 0-2846 A-1 APPENDIX
APPENDIX 1: INPUT WIRING REQUIREMENTS
NOTES
The table above is based on the following output current and voltage: 125 vdc @ 40A
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired installations refer
to local or national codes.
Cable conductor temperature used is 167° F (75° C).
An energy limiting fuse UL Class RK-1 (examples: BUSS LPS/LPN-RK or Gould-Shawmut AZK-A6K) should be
used to minimize damage to Plasma Cutting, Welding or power distribution equipment.
NEVER use replaceable element fuses like UL Class H, or "one-time" fuses like UL Class K5.
Power Input Current Input
Voltage Frequency 1-Ph 1-Ph Fuse (Amps) Wire (AWG) Wire (Canada)
(Volts) (Hz) (kVA) (Amps) 1-Ph 1-Ph 1-Ph
208 60 8.2 39 45 8 8
230 60 8.2 37 45 8 8
Suggested Sizes (See Notes)Input
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
