ASSEMBLY
3
Attach the Lower Post
G
to the Post Supports
I
. Once
you have tightened the bolts holding the Post Supports
I
to the Base
J
, align the holes in the Lower Post
G
with the
holes on the tops of the Post Supports and insert a Large
Bolt
through the hole in the Post Support. Secure with a
Small Flange Nut
!
. Repeat this in the 5 remaining holes (6
holes total—2 for each Post Support piece). Hand tighten
initially then tighten with the Wrench
(
when all bolts
have been inserted.
Hardware Used: 6x Large Bolt
6x Small Flange Nut
!
4
Attach Upper Post
F
to Lower Post
G
by screwing the
two pieces of the post together.
Note: Bolts not needed to hold the posts in place.
5
Slide Tank Housing
D
over the assembled Upper/Lower
Posts
F
/
G
and down over the Post Supports
I
. Rest the
Tank Housing on the Base
J
.
6
Attach "¿to the top of the Head½
Assembly
C
. Insert 1 through 1 Large Flat
Washer
#½and into the hole on the top of the Head Assembly.¿
Tighten stud securely. Repeat with the other 2¿,gtgU¿³½-¿Å_¶¦
Hardware Used:
"
3x Large Flat Washer
#
6
