3. WALK TEST - This function allows the user to test
fire detectors and callpoints on the system.
To put a zone into Walktest – Enter user code
5344. Press 3 – WALKTEST. The FAULT led of the
first available zone flashes quickly.
Press 4 to select this zone for testing. This causes the
fault led of the selected zone to flash slowly –
showing that this zone is in test along with the test
led being illuminated.
If a zone is in Walktest, the TEST led is lit and the
FAULT led of the corresponding zone flashes slowly.
PERFORM WALKTEST
Walk round and test detectors and/or call points in
this zone. When a device is triggered the sounders will
sound a few seconds and then silence. The relevant
FIRE zone indicator on the panel will be flashed.
DESELECT WALKTEST
When all of the detectors and/or call points have
been tested in the zone, re-enter the access code
(5344), Press 3 and then Press 4 to deselect this
zone. The zone in Walktest must be deselected
before another zone can be put into Walktest. Only
one zone can be put into Walktest at any one time, all
other zones operate as normal.
SELECT NEXT WALKTEST
Re-enter the access code (5344), Press 3 and then
Press 3 to advance to the next zone that is available
for Walktesting. The FAULT led of the next zone
flashes quickly.
Press 4 to select zone for
walktesting. Perform Walktest.
Press 5 To exit from this menu.
4. EVACUATE – This is used to activate the fire
alarm sounders. But does not trigger any device
connected to the auxiliary contacts (Typically a
digital communicator and/or heating/ventilation
controls) The internal buzzer will sound and the
GENERAL FIRE indicator will be illuminated.
5. LAMP TEST - This option illuminates all the LED’s
and twice beeps the internal buzzer. After 3
seconds the LED’s revert back to their previous
state and the panel to its normal condition.
LEVEL 2b USER CODE 5344
Enter this code to gain access to the bottom row of
instructions. The lower yellow led will light indicating
that this row of functions can now be activated by
pressing the appropriate button above it. The
functions are as follows:-
1.
RESET - is used to return the fire alarm system to
the normal clear condition, resetting any fire
alarm detectors, silencing all the sounders, and
resetting other devices connected to the panel.
2.
SILENCE BUZZER – Causes the internal buzzer to
be switched off during a fire or fault condition.
Any subsequent fault or fire activation on another
zone will cause the buzzer to be re sounded.
