Firex AD Quick Start Guide

TROUB L ESHOOTING
A DANGER : Always tum off power at main fuse box
or c ircuit breaker before taking trouble-
shooting action.
PROBLEM SOLUTION
Smoke alarm does not
1. Check that AC power
sound when tested.
is turned on .
2. Turn off power. Remove smoke
NOTE: Push test button for
alarm from mounting plate and:
at least five
(5) seconds
a. check that connector plug is
while testing!
securely attached.
b. check that battery is proper-
ly attached to connector.
3. Clean smoke alarm.
The horn makes
2 quiet
The alarm is operat
in g
beeps
and one loud beep
correctly. Model ADC has a
when tested.
ramp-up test horn feature. This
allows you
to release the test
button before the alarm emits
the loud beeps.
Smoke alarm beeps about
1. Turn off power and replace
once a minute. battery. (See "Battery
Replacement" in the
MAINTENANCE AND
CLEANING section
.)
2. On Model ADC only - be sure
the red LED is extinguished
after replacing the battery.
Smoke alarm
so unds 1. Hire an electrician to
unwanted alarms inter-
move smoke alarm to
mittently or when a new location. See
residents are cooking, SMOKE ALARM
taking showers, etc. PLACEMENT
2. Clean smoke alarm.
See "Cleaning"
in the
MAINTENANCE AND
CLEANING section.
,Interconnected smoke Press and hold TEST
alarms
do not sound when
button for at least
system is tested.
three seconds after
the first
un it sounds.
The alarm sounds different
The ala
rm is operating cor-
than I'm used to. It starts and
rectly. This alarm features
stops. the internationally recognized
horn signal
fo r evacuation. The
horn pattern is 3 short beeps
fo llo wed by a 2 second pause
and then repeats.
WARRANTY INFORMATION
To return Ultra life 10-year lithium batteries under warranty, include the
lithium battery, a
note describing the nature ofthe difficulty, with proof
of date of purchase, postage and return postage prepaid to:
ULTRALIFE BATIERIES, INC .
c/o
CLIMATE CONTROLS AMERICAS
P.O. Box 622
1350 Route 88 South
Newark, NY 14513
Climate Controls Americas
191 E. North Avenue
Carol Stream illinois 60188
United States of America
5- YEAR LIMITED SMOKE ALARM WARRANTY AND
IO -Y EAR LIMITED ULTRALIFE U9VL-J LITHIUM BATTERY WARRANTY
(WHEN SOLD WITH CLIMATE CONTROLS AMERICAS SMOKE ALARM)
Climate Controls Americas warrants to the original consumer purchaser
each new smoke alarm to be free from defects in material and workmanship
under normal use and service for a period of five (5) years from the date of
purchase . For Climate Controls Americas smoke alarms sold with an Ultralife
U9VL-J 9- volt battery, C limate Controls Americas warrants to the original
consumer purchaser each new Ultra life U9VL-J 9- volt battery to be free
from defects in material and workmanship under normal use and service for
a period of ten (10) years from the date of purchase. Cl imate Controls
Americas agrees to repair or replace, at its option, any defective smoke
al arm or Ultra l ife U9VL -J 9-volt battery - Iwhen sold with Cl i mate Controls
Americas smoke alarm) provided that it is returned with postage prepaid and
with proof of purchase date to Cl i mate Controls Americas. This warranty
does not cover damage resulting from accident, misuse or abuse or lack of
reasonable care of the product. This warranty is in lieu of all other express
w arranties, obligations or liabilities. THE IMPLIED WARRANTIES OF MER -
CHANTABILITY AND FITNESS FOR A PA RTICULAR PURPOSE ARE LIMITED
TO A PERIOD OF FIVE (5 ) YEARS FOR THE SMOKE ALARM AND TEN (1 0)
YEARS FOR THE ULTRALIFE LITHIUM U9VL -J 9-VOLT BATI E RY (WHEN SOLD
WITH CLIMATE CONTROLS AMERICAS SMOKE ALARM) FROM PURCHASE
DATE . Some states do not allow limitations on how l ong an implied warran-
ty lasts, so the above limitations may not apply to y ou . IN NO CASE SHALL
CLIMATE CONTROLS AMERICAS BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WAR-
RANTY, EXPRESS OR IMPLIED, WHATSOEVER, EVEN IFTHE LOSS OR DAM-
AGE IS CAUSEO BY ITS NEGLIGENCE OR FAULT. Some states do not allow
the exclusion or lim itation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you
specific legal rights, and you may also have other legal rights which vary
from state to state.
This smoke alarm 's manufacture an d distribution are licensed by the U.S.
Nuclear Regulatory Commission .
This product meets all the requirem ents of U.L. Standard 217 .
~ensy s ~
DO NOT disconnect battery or AC
po w er to quiet an unwanted alarm.
This will remove your protection. Fan
t he ai r or open a window to remove
s mo ke or dust.
A WARNING:
PRACTICE FIRE S AFETY
If the s mok e alarmso unds its alarm horn, and y ou ha ve not p ushe d the test bu t-
ton, it is w arnin g of ad angerous si tuat i on.
Your immedia te res po nse is n ec es sary. To prepare for s uc hoccu rrences, d ev elop
f ami ly escap epl an s,d iscuss them wi th
ALL househol d membe rs, and pra ctic et hem regularl y.
• Expose e very one to the sound of asm oke alarm and ex pl a in w hat t he sound
mea ns.
•
Determine TWO exits from each room and an escape route to the outs i de from
each ex it.
• Teach all household mem b ers toto uch the door and usean alternate exit if the
door is hot. INSTRUCT T HE MNOT TO OPEN THE D OO R IF THE DOOR IS
HOT.
• Teach h ou seh old me mbers to cr awl along the f loor to stay below dangerou s
s
mok e, fumes, a nd gases.
• De te rmine a saf em eeting place for all members outside the buildin g.
::LEANING
~Iean the smoke alarm at least once a month to remove dust, dirt,
Jr debris.Always turn off power to smoke alarm before cleaning.
• Using the soft brush
or wand attachment to a vacuum cleaner,
vacuum all sides and cover of smoke alarm. Be sure all the
vents are free
of debris.
• If necessary, turn off power and use a
damp cloth to clean
smoke alarm cover.
• Do not spray smoke alarm with cleaners. Always place cleaners
on cloth first, then wipe smoke alarm with cloth.
M PORTANT : Do not attemptto remove the cover or clean inside the
smoke alarm. THIS WILL VOID YOUR WARRANTY.
WHAT TO 00 IN CASE OF A FIRE
1. D on 't panic; stay c al m.
2. Leave t he bUilding as quickly as possible . Touch doors to feel if they are hot
b efore openi ngt he m. Use an alterna t e xit If necessary. C rawl along the f loor,
and DO NOT stop to collect any1hing.
3. Mee t at apr e-arranged meeting place ou t side thebu ilding .
4. Ca ll t he fi re departmen t from OUTSIDE th ebuil ding.
5. DO NOT GO BACK IN SIDE ABU RNING B UILDI N G. Walt for the fire departmen t
to arrive.
These guidelines w ill assist you in the ev ent of a fire. However, to reduce the chance
that f ires w ill start, pr ac ti ce fi re sa f ety ru le sand preve nt hazar do us situati ons.
RE PAIR
A. CAUTION: Do n ot attem pt to repai r t his sm oke
alar m. Doing so will vo id your war ra nty.
If smoke alarm is not operating proper ly, see TROUBLESHOOTING.
If necessary, and if still under warranty, return smoke alarm to
:::Iimate Controls Americas. Pack it in a well-padded carton, shipping
prepaid, with a note describing the nature of the problem and proof of
the date of purchase to:
Cl imate Controls Am ericas
Product Service Department
28C Leigh Fisher Bl v d.
EI Paso , TX 79906
If the smoke alarm is no longer under warranty, have a licensed
electrician replace the smoke alarm immediately with a compara-
ble Firex brand smoke alarm.
1 1
12
