CM6000 Install Guide
Alarm and Starter System
www.firstechonline.com | www.compustar.com
Alternator Sensing
Alternator sensing is an alternative method the remote start can utilize to determine if the engine is running.
This is different than the no tach sensing mode so a connection must be made. IMPORTANT: The remotes
must be coded prior to setting up alternator sensing.
STEP 1: Change Option 2-10 to setting 2 - Alternator sensing.
STEP 2: Test wire and make connection. The stator wire is found at the vehicle’s alternator. Change your
multimeter to DC voltage before testing for this wire.
A. At rest, with the ignition off, the stator wire should test 0V DC.
B. Turn the ignition to the run position. The stator wire should now test between 4 – 6V DC.
C. Start the vehicle with the key. The stator wire should now test between 12 – 14V DC at idle.
STEP 3: Process complete – no further programming is required.
Tachless Mode – (Automatic Transmission Vehicles Only)
Tachless sensing is an alternative engine sensing mode. It does not require a connection to the vehicle other
than the main ignition harness.
STEP 1: Change Option 2-10 to setting 3 – Tachless Mode.
STEP 2: Process complete – there is no further programming required other than adjusting crank time
when necessary (see below).
Adjusting Crank Time: To adjust minimum crank times, refer to Option 2-12. To help ensure successful
starting, the system will automatically add additional crank time to the 2nd and 3rd start attempts. In
addition, there is a built in “Smart Resting Mode”. Traditional tach sensing is still highly recommended for
colder climates.
Timed Crank Setting – Automatic Transmissions Only
Option 2-10 setting 4 provides a timed 1.5 second crank for the remote start sequence. This option just
cranks the vehicle for 1.5 seconds and assumes remote start has completed. This option can be used for
GM and other vehicles with built in anti-grind systems.
Green/White Loop
This loop wire determines the transmission setting. The default position (uncut loop) is for manual
transmissions. When the loop is cut, the system will be ready for automatic transmissions. In the default
(manual transmission) mode, the system must be set up in Reservation mode prior to the vehicle being able
to remote start. IMPORTANT: All warranties or claims are void if a controller with a cut loop is installed on
a vehicle with a manual transmission.
Reservation Mode for Manual Transmissions
To remote start a manual transmission vehicle, the system must first be set up in reservation mode.
Reservation mode is designed to prevent the vehicle from remote starting while the transmission is in gear.
Copyright 2011 Firstech, LLC.
Page 13
