Connector 11 (CN11), 2-Pin (Pre-wired LED)
Note: Do not mistake for Thermister port.
Pin 1 Black - L.E.D negative (-) ground.
Pin 2 Black/White- L.E.D. 3V positive (+) output.
Connector 12 (CN12), 4-Pin (Pre-wired RPS)
Pin 1 Black - Negative (-) ground.
Pin 2 White - Negative (-) paging input.
Pin 3 Red - 12V positive (+) output.
Pin 4 Yellow - 9V positive (+) L.E.D. output.
Connector 13 (CN13), 4-Pin (Pre-wired Shock Sensor or DAS Sensor)
Pin 1 Black - Negative (-) ground.
Pin 2 White - 2nd stage negative (-) input. (Instant trigger)
Pin 3 Red - 12V positive (+) output.
Pin 4 Yellow - 1st stage negative (-) input. (Warn away)
Connector 14 (CN14), 4-Pin (Optional Sensor Input)
This connector provides optional sensor inputs. Most commonly used with proximity and tilt sensors.
Pin 1 Black – Negative (-) ground.
Pin 2 Black/White - 2nd stage negative (-) input. (Instant trigger) (Arm)
Pin 3 Red – 12V positive (+) output.
Pin 4 Grey/White - 1st stage negative (-) input. (Warn away) (Disarm)
