Firstech CM6300 - Option Menu Descriptions

Special Option Group 1
Feature Setting Value (Seconds)
2 AUX1 output time 1 ~ 100
3 AUX2 output time 1 ~ 100
4 AUX3 output time 1 ~ 100
5 AUX4 output time 1 ~ 100
6 AUX5 output time 1 ~ 100
7 AUX6 output time 1 ~ 100
8 AUX7 output time 1 ~ 100
Option Menu Descriptions CM6300
1-02 Door Lock/Unlock Pulse Duration - This feature determines the output duration of the door lock and
unlock pulses. Some vehicles do not respond to short door lock/unlock pulses. This does not affect
the output of the factory arm (orange wire CN3)or factory alarm disarm (orange/white wire CN3).
1-03 Driver’s Priority Unlock - If enabled, this feature will allow the user to unlock the driver’s door first,
and if the unlock button is pressed again within 4 seconds, the other doors will unlock. The driver’s
door unlock must be isolated from the other doors and use the blue (-) unlock. The Orange/Black
CN4 will be used for your 2nd Unlock output to unlock all other doors.
CM6300 Install Guide
Alarm System
www.firstechonline.com | www.compustar.com
Copyright 2012 Firstech, LLC.
Page 22
Special Option Group 2
Feature Setting and OP500 Value
Programmable
Output
Connector
0 - Default Setting 1~18 – Optional Settings
1 POC #1 (-) 2nd Parking Light (Green/White)
2nd Light - [1] 2nd Start - [2] 2nd IG1 - [3]
2nd Acc - [4] Status Out - [5] Rearm Out - [6]
Disarm Out - [7] Horn Out - [8] Dome Light - [9]
Aux 1 Out - [10] Aux 2 Out - [11] Aux 3 - [12]
Aux 4 Out - [13] Aux 5 Out - [14] Aux 6 Out - [15]
Aux 7 Out – [16] N/A - [17] GWA - [18]
2 POC #2 (-) Aux 5 (Red/Black)
3 POC #3 (-) Aux 4 (Green)
4 POC #4 (-) Aux 3 (White/Black)
5 POC #5 (-) Aux 2 (Black)
6 POC #6 (-) Rearm Wire (Orange)
7 POC #7 (-) Disarm Wire (Orange/White)
8 POC #8 (-) Horn (White)
9 POC #9 (-) Aux 1 (Violet)
