CM6300 Install Guide
Alarm System
www.firstechonline.com | www.compustar.com
Copyright 2012 Firstech, LLC.
Page 21
Option Group 4
Feature Default Setting - I
Optional Setting
- II
Optional Setting
- III
Optional Setting
- IV
4-01
Aux 1 output 0.5sec Latch
0.5 sec Pulse +
Program
Program
4-02
Aux 2 output 0.5sec Latch
0.5 sec Pulse +
Program
Program
4-03
Aux 1 output Control By Remote Arm Disarm Ignition Shutdown
4-04
Aux 2 output Control By Remote Arm Disarm Start
4-05
Secure Aux Output
(1 and 2 Only)
On Off
4-06
Auxiliary Input 1 – Green CN Prewarn Trigger (-)Disarm Open Circuit
4-07
Auxiliary Input 2 – Green CN Trigger Prewarn (-)Arm Open Circuit
4-08
Extended Accessory After Ign
Shutoff (Negative Out)
Off 10 sec 90 sec
Until Door Open (1
min max)
4-09
Key Sense or Glow Plug input Glow Plug Input Key Sense Input
Disable Arm/Disarm
when Brown/White
Wire Triggered Same
Time
4-11
Bypass Through RS232 Port ADS Fortin
4-12
Impact Sensor Shock Sensor DAS Sensor
1st Stage Disarm Input
| 2nd Stage Double
Arm Input
1st Stage Disarm Input
| 2nd Stage Arm Input
4-13
Antenna Power Save Off 1 Day Later 2 Days Later 3 Days Later
4-14
Low Battery Warning Off On (at 11.3 volts)
Low Battery Start
(11.3 volts)
Low Battery Start
(11.7 volts)
Option Group 3 Continued
Feature Default Setting - I
Optional Setting
- II
Optional Setting
- III
Optional Setting
- IV
3-08
Horn Output On Double Lock Only On Lock and Unlock
On Lock, Unlock, and
Start
On Double Lock and
Start
3-09
Siren Output
On Lock, Unlock, and
Start
On Double Lock Only On Lock and Unlock
On Double Lock and
Start
3-10
Valet
Key 5 times, or
Remote (I+III) while
Ignition is On
Key 5 times or Remote
(I+III)
Secure Valet
(Default code 3,3)
3-11
Auxiliary Settings Mode Disabled Enabled
3-15
Soft Disarm Off On
3-16
RPS RPS 2 RPS Touch
