FISCHER 63298 - Parts List and Diagram; Part Description

Page 14 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 63298
EF;6GH IJ6KFGLIM NFLMG6MFMO6FEE6NPQH EF;6GH IJ6KFGLIM NFLMG6MFMO6FEE6NPQH
J,($#%Q"#$%,89%`",3(,5
J,($#%Q"#$
J,($ `*#4("/$"&8 g$R
1 Wheel 2
2 Base 1
3 Wheel Bolt M12 x 100 2
4 Nut M12 2
5 Large End Cap 6
6 Bolt M12 x 95 2
7 Bolt M12 x 65 2
8 Flat Washer 16
9 Lock Washer 4
10 Nut M12 4
11 Support Bar 2
12 Cotter Pin 2
13 Safety Lock Lever 2
14 Rivet 2
15 Spring 2
16 Pin 2
17 Handle Bolt M10 x 20 2
18 Lock Washer 2
19 Flat Washer 2
20 Shaft 1
21 Lower Lift Arm 1
22 Handle 1
J,($ `*#4("/$"&8 g$R
23 R-Clip 17
24 Long Lift Arm Rod 1
25 Short Lift Arm Rod 1
26 Upper Lift Arm 1
27 Rubber Pad 3
28 Screw 4
29 Nut 4
30 Small End Cap 4
31 Width Pin 2
32 Wheel Bracket Rod 4
33 Cross Beam 1
34 Wheel Bracket 2
35 Plate 1
36 Cross Beam Pin 1
37 Handle End Cap 1
38 Upper Ram Pin 1
39 Lower Ram Pin 1
40 Foot Pedal 1
41 Foot Pedal Bolt M8 x 16 1
42 Lock Washer 1
43 Ram 1
