Fisher & Paykel ACTIVESMART RS36A72 User Manual

5
Door panel set
Door panel set:
Non-Water dispensing French panel (1x)
Ice & Water French panel (1x)
Drawer panel (1x)
Model numbers:
RD3672 or RD3672U
Door panel set:
Non-Water dispensing French panels (2x)
Drawer panel (1x)
Door handle kit — not included with the refrigerator and must be purchased separately
Professional rounded door handle (3x)
OR
Contemporary square door handle (3x)
M5 x 25
Pan Head
Socket Screw
M5 x 25
Pan Head
Socket Screw
M5 x 14
Mush Head
SS
Philips Screw
M5 x 14
Mush Head
SS
Philips Screw
M5x25 pan head socket screw (12x) M5x14 Mush Phillips SS (34x)
2 COMPONENTS LIST
Door panel fittings — included with the refrigerator
French door hanging
bracket (2x)
Drawer hanging bracket
(1x)
Side bracket (10x)
M5 x 10
Pan Head
Philips Screw
M5 x 10
Pan Head
Philips Screw
#8 x 5/8
Pan Head
Philips Screw
#8 x 5/8
Pan Head
Philips Screw
Side strap (10x) M5x10 pan head Phillips
screw (10x)
#8x16 panhead Philips
screw (34x)
M8 Stud
M8 Stud
M8 Washer
M8 Washer
M8 Nut
M8 Nut
M8 stud (6x) M8 washer (6x) M8 nut (6x)
Side cover (4x) Top cover (2x)
Fisher & Paykel
(Stainless steel)
door panel set is
not included with
the refrigerator
and must be
purchased
separately.
Custom door panel
set is only applicable
for non-Water
dispensing models.
Customers can
supply their own
Custom door panel to
match their cabinetry.
