DIMENSIONS- Milimeteres
Models
DishDrawer® Tall
Double
DishDrawer® Tall
Single
DD24DCTX6
DD24DCTW6
DD24DCTB6
DD24DDFTX6 DD24DTI6
DD24SCTX6
DD24SCTW6
DD24SCTB6
DD24SDFTX6
DD24STI6
456mm cavity
DD24STI6
480mm cavity
PRODUCT DIMENSIONS
Overall height* of product
863.5- 923.5
863.5- 923.5 863.5- 923.5 453 477 453 477
Overall width of product 595 595 595 595 595 595 595
Overall depth of product (excl.
curvature/handle)
570 570 570 570 570 570*** 570***
Depth of drawer (open) (excl.
curvature/handle)
520 520 520 520 520 520 520
Height* of chassis 853 853 853
453 453 453 453
Height range of levelling feet 60 60 60 - - - -
Depth of chassis
552 552 552 552 552 552 552
Depth of drawer front panel
(excl. curvature/handle)
18 18 18 18 18 18 18
Depth of curvature or handle 11 41 n/a 11 41 n/a n/a
Depth of toekick 50-110 50-110 67-127**** - - - -
Height of upper drawer front 438 442 442 min - - - -
Height of lower drawer front 307 312 312 min - - - -
Height of toekick (adjustable) 70-120 70-120 70-120 - - - -
Height of venting area at base
of product
- - - 7 9 9 9
Height of installation bracket
slots (on top of chassis)
2 2 2 2 2 2 2
Height of drawer fronts 751 764 762 min 438 470
442 min
470 min
Height of top of upper drawer
to top of chassis
7 2 n/a - - - -
CABINETRY DIMENSIONS
Inside height of cavity 864-926.5 864-926.5 864-926.5 456 480 456 480
Inside width of cavity 600 600 600 600 600 600 600
Inside depth of cavity (inside) 580 580 580 580 580 580 580
Height of adjacent cabinetry 762 762 Min. 764 - - - -
Height of toekick 70-120 70-120 70-120 - - - -
Clearance below benchtop** Min. 3 Min. 3 Min. 3 Min. 3
* Chassis height include bracket slots
** Clearance is measured from the underside of benchtop to the chassis
*** Panel thickness- 18mm
**** Prefinished 50-65mm Integrated 67mm less the Toekick Panel thickness (minimum Panel thickness using the supplied screws is 9mm).
Product Code: FPDD605
