Fisher & Paykel DD24S - Product Dimensions; Cabinetry Dimensions

Minimum clearances (inches (mm))
⁄” (2.5 mm)
⁄” (2.5 mm)
½
” (13 mm)
23
PRODUCT DIMENSIONS CABINETRY DIMENSIONS
A
B
C
E
D
F
G
H
J
K
Product dimensions (inches (mm))
Pre nished
LCD
DD24S
Pre nished
Flat door
DD24S
Integrated
DD24S
A
overall height* of product
16 ⁄” (409) 16 ⁄” (409) 16 ⁄” (409)
B
overall width of product
23 ⁄”(599) 23 ⁄”(599) 23 ⁄”(599)
C
overall depth of product (excl. curvature/handle)
22 ⁄” (570) 22 ⁄” (570) 22 ⁄” (570)**
D
depth of drawer (open) (excl. curvature/handle)
21 ⁄” (538) 21 ⁄” (538) 21 ⁄” (538)
E
height* of chassis
16 ⁄” (409) 16 ⁄” (409) 16 ⁄” (409)
F
depth of chassis (incl. trimseal)
21 ¾ ” (552) 21 ¾ ” (552) 21 ¾ ” (552)
G
depth of drawer front panel (excl. curvature/handle)
⁄” (18) ⁄” (18) ⁄” (18)
H
depth of curvature or handle
⁄” (11) 1 ⁄” (41) n/a
I
height of drawer front
15 ½ ” (394) 15 ⁄” (398) 15 ⁄” (398) min
J
height of venting area at base of product
¼ ” (7) ⁄” (9) ⁄” (9)
K
height of installation bracket slots (on top of chassis)
⁄” (2) ⁄” (2) ⁄” (2)
*Chassis heights include bracket slots ** Panel thickness - ⁄” (18 mm)
Note: for Pre nished Flat door models, the height from the top of handle to the top of door - 2
½ ” (64 mm)
I
Installation diagrams for illustration purposes only
A
B
C
Cabinetry dimensions (inches (mm))
Pre nished
LCD
DD24S
Pre nished
Flat door
DD24S
Integrated
DD24S
A
inside height of cavity
16 ¼ ” (412) 16 ¼ ” (412) 16 ¼ ” (412)
B
inside width of cavity
23 ⁄” (600) 23 ⁄” (600) 23 ⁄” (600)
C
inside depth of cavity
22 ⁄” (580) 22 ⁄” (580) 22 ⁄” (580)
K
F
C
H
Installation diagrams for illustration purposes only
