Fisher & Paykel HC60DCXB1 - Installation Instructions

4
Installation instructions
3 4
1
2
250 mm
C
235 mm
D
B

A
MIN. 660
mm
Model HC60DCXB1 HC90DCXB1 HC120DCXB1
A 420 mm 580 mm 900 mm
B 273 mm 273 mm 268 mm
C 250 mm 250 mm 245.5 mm
D 36 mm 36 mm 42.5 mm
