HC60 HC90 HC120
PRODUCT DIMENSIONS mm
A
Overall height of product 595 – 1035 595 – 1035 595 – 1035
B
Overall width of product 598 898 1198
C
Overall depth of product 500 500 500
D
Height of hood 55 55 55
E
Height of stainless strip 27 27 27
F
Width of chimney 320 320 320
G
Depth of chimney 290 290 290
H
Distance from centre of ducting
outlet to back of product
105 105 105
I
Distance from centre of ducting
outlet to side of chimney
160 160 160
J
Diameter of ducting outlet 150 150 150
K
Distance between centre of lights 230 230 230
L
Distance from centre of lights to
back of product
45 45 45
Length of power cord 1500 1500 1500
IMPORTANT!
Actual product dimensions may vary by ± 2mm.
Please read the entire instructions before installing the rangehood.
To Next Page
