10
INSTALLATION INSTRUCTIONS
Height of rangehood
N
M
INSTALLATION DIMENSIONS mm
M
Installation height
Ducted
Recirculation
min. 635 – max. 1035
min. 675 – max. 1035
N
Height top of cooktop to base of product
Electric cooktop
Gas cooktop
min. 600 – max. 750
min. 650 – max. 750
Rangehood installation height above the cooktop is the user’s preference. Lower
installation heights will improve the efficiency of capturing cooking odours, grease,
and smoke. This rangehood must be installed between the minimum and maximum
dimensions indicated in the table above.
