INSTALLATION GUIDE
10
1
2
3
Before positioning your washer in its final
position, check that the machine is level,
front to back and side to side.
Level the washer side to side:
1 Place the level on the centre front of
the washer.
2 If you need to adjust the washer’s
position, loosen the lock nut using the
spanner provided and turn the feet up or
down until the washer is level side to side.
To wind the feet up turn clockwise, to wind
the feet down turn counter-clockwise.
Level the washer front to back:
1 Place the level on the left side, in line with
the centre of the washer.
2 Adjust the front left foot and then the
right foot until the washer is level.
There should be equal weight on both
front feet.
Using the spanner provided, tighten the
lock nuts against the base of the washer
tolockthe feet in position.
Move and centre the washer into its final
position within the cavity, using adjacent walls
as a guide and allowing 20mm clearance at
the back and sides of the washer.
Recheck the washer is level, front to back
and side to side. Repeat the above steps
if required.
Levelling the washer
It is IMPORTANT to level the washer. Having a level washer set up in its cavity will
ensure best performance for spinning, minimising noise, vibrations and wear and tear on
the washer.
