Fisher CA-77 - Page 7

ACKING PARTS LIST
ef. No. Parts Number
131 6 1169 07000
131 62119 02131
131 6 3009 33930
131 6 3009 33940
131 6 3069 16350
Description
Box Corrugate-EXP
Bag Polyethylene-EXP
Pad (Left}
Pad (Right)
Patching Sheet
CCESSORIES PARTS LIST
ef.No. Parts Number
131 6 4169 03100
131 6 4319 10802
131 6 4519 14400
131 6 4939 00200
ABINET PARTS LIST
ef. No. Parts Number
?
131 2 1410 28900
131 2 1801 12900
Description
Explanatory Booklet
Service Station List
Guarantee Card
Information Card
Description
Cover
Leg
PPEARANCE PARTS LIST
ef. No. Parts Number
Wa WY ™ OI Ol RR WN MY WH a
131 2 1203 57500
131 2 1203 57600
131 2 1203 57700
131 2 1207 13000
131 2 1601 71001
131 2 1601 83700
131 2 1601 85500
131 2 1601 85600
131 2 3101 87700
131 2 4208 41200
131 2 5205 28500
131 2 6113 48000
131 2 6113 48700
141 2 1659 08000
141 2 1659 08100
Description
Panel Control
Panel Control
Panel Control
Housing (Touch SW.)
Knob (Tone EQ)
Knob (Power Switch)
Knob (Master Volume)
Knob (Mic Mix, Balance)
Metal Mount
Spacer (Touch SW.)
Cushion
Shelter
Shelter (EQ)
Knob (Speaker Switch)
Knob (Push Switch)
PARTS LIST
CHASSIS PARTS LIST
Ref. No. Parts Number
20 131 2 1410 28800
21 * 13123101 71300
22 * 13123101 87800
23 * 13123101 87900
24 * 13123301 29800
25 * 131 2 3305 34000
26 * 131 2 3306 36800
27 = * 131 2 3614 20300
28 131 2 4201 17800
29 131 2 4219 16200
30 131 2 4219 17100
31 131 2 4219 17400
32 131 2 6103 23200
33 131 26111 14200
34 131 2 6201 32000
Description
Cover (Bottom)
Metal Mount ({C)
Metal Mount
Metal Mount (Heat Sink)
Chassis
Panel Front
Panel Rear
Mount P.C.B.
Screw (GND)
Shaft (Push Switch)
Shaft (Power Switch)
Shaft (Speaker Switch)
Cover Shield
Bushing (Line Cord)
Heat Sink
ELECTRICAL PARTS LIST
Ref. No. Parts Number
40 4 2359 23421
41 4 2432 00340
42 4 2512 19100
43 131 0 4001 11440
44 131 0 4001 11450
45 131 0 4001 11460
46 131 0 4001 11470
47 131 0 4001 11480
48 131 0 4001 11490
Description
AC Socket
Line Cord
Power Transformer
Main P.C.B. Assy
Graphic EO P.C.B. Assy
Volume P.C.B. Assy
Power SW. P.C.B. Assy
Speaker Terminal P.C.B. Assy
L.E.D., Function SW. P.C.B. Assy
*_Not a service part.
