PREPARATION
Tools
• Caliper • Router with 1/8" (3mm) Straight Bit (single flute)
• 400 Grit Sandpaper or Scraper • Soldering Iron (30 watt max)
• Rosin Core Solder • Wire Strippers
• Masking Tape • X-Acto Saw
• Variable Speed Drill • Center Punch
• 1/8" Twist Drill • 15/32" Spade Bit Drill
• 1/2" Open End Wrench • 3/32" Allen Wrench
MECHANICAL FACTORS AFFECTING PICKUP PERFORMANCE
Break Angle
For the pickup to perform optimally, there should be a 20° (minimum) string break
angle across the back of the saddle. An adequate break angle can be realized by
"ramping" the string slots. In extreme cases, where the break angle is less than
20°and the saddle is so low that it is nearly flush with the top of the bridge, the
instrument probably requires a neck re-set. In these cases, re-setting the neck to a
higher angle will restore the saddle height and the string break angle required for
good pickup performance.
3
3
Installation Guide
Installation Guide
IIMMPPOORRTTAANNTT
Installation of the AG Series Acoustic Guitar Pickup requires fine woodworking & soldering
skills and should be performed only by a qualified repairman. Fishman Transducers will not be
responsible for any damages that may result from improper installation.
Please read these instructions carefully. For technical assistance, contact Fishman
Customer Support at 978-988-9665 or tech@fishman.com.
If you are new to under saddle piezo installations, a comprehensive guide, The Finer Points of
Piezo Installation by Ken Parker, is available at www.fishman.com.
Handle the pickup carefully! Mishandling may result in ground hum or intermittent signal.
Fishman Transducers will not be responsible for any damages to the pickup that may occur
due to misuse or poor installation.
