Fishman BP-100 User Guide

5
Mount the pickup
Caution: do not pull or bend the wires at the bases of
the elements. You may destroy the pickup!
1. Slide the pickup wire through the E-string side
wing slot.
2. Center the elements black side up on the side of
the bridge that faces the fi ngerboard, as shown, with
the straight edge
1
⁄
8
” below the top edge bevel of the
bridge top. The felt-covered clip should be pushed
tightly against the top of the bridge. A loose clip may
be tightened by squeezing it before installation.
3. Weave the ground wire over the string ball-ends
making sure to contact each ball.
4. Determine which isolation plug fi ts snugly into the
E-string side wing-hole on the bridge. Slip the wire
into the slit of the isolation plug and fi t the plug into
the wing-hole.
GROUND
WIRE
OUTPUT
WIRE
