Fishman POWERBRIDGE User Manual

4
Stereo Operation
Stereo Jack • A 1/4” stereo output jack is provided with your Powerbridge
pickup. With it, the piezo and magnetic pickup signals will be sent to separate
amplifi ers. In active (Powerchip) or passive installations, stereo function will
remain the same. The magnetic pickups are wired to tip, and the Powerbridge
pickup is wired to ring.
Cables • For best results, use a “2-pair” premium stereo or stereo “Y” cable
(available through your Fishman dealer) with separate shielding for both the Pow-
erbridge and magnetic signals.
Sleeve Ring Tip

Fishman POWERBRIDGE Specifications

General

Type	Acoustic Guitar Pickup
Compatibility	Acoustic Guitars
Installation	Professional installation recommended
Pickup type	Piezo
Technology	Piezo
Output	Mono
