Stereo Operation (Examples)
Powerbridge Signal
(Ring)
P.A. / Recording
Console
Amp with Tip/Ring/Sleeve
Stereo Input
Electric Guitar
Amp
Magnetic Signal
(Tip)
Magnetic Signal
(Tip)
Active
D.I.
Powerbridge Signal
(Ring)
Stereo Cable
Signal Path
Stereo “Y” Cable
Signal Path
