Step 6.
Well connect the wires from Handlebar
Post (6) and Main Frame (1).
Assembly Instruction
Step 5.
Remove bolts from the front of Main
Frame. Be sure to keep Computer Wire
outside the frame for further assembly.
Step 7.
Insert Handlebar Post (6) into Main Frame
(1) then secure by Screws & Washers (B).
2 curve washers are for the front side, and
4 flat washers are for right and left side. Be
careful not to cut the wires.
Step 8.
Remove Screw & Washer from Handlebar
Post (6). (Please note there is string
attached inside Handlebar Post (6).)
