Assembly Instruction
Step 9.
Use the string at hole A of Handlebar
Post (6) to tie up the Pulse Cable from
Handlebar (3), then pull the string from top
end of Handlebar Post (6) to let the Pulse
Cable go through Handlebar Post (6) to the
top opening of Handlebar Post (6). Be sure
to keep Pulse Cable and Computer Cable
(from Main Frame) outside the frame for
further assembly.
Step 10.
Attach Handlebar (3) to Handlebar Post
(6) and secure by Screw & Washer (c). Be
careful not to cut the Pulse Cable.
Step 11.
Remove screws from Computer (7) then
well connect all the cables from Computer
(7) and Handlebar Post (6)
Step 12.
Place Computer (7) at the top of Handlebar
Post (6), then insert all the cables into the
hole of handlebar post and secure by the
screws from computer. Be careful not to cut
the cables.
hole A
