FIVE OCEANS ATLANTIC Series - Fitting; Electrical; Installation; Basic Requirements

5
FIVE OCEANS ATLANTIC SERIES
3.2 Fing3.2 Fing
• This equipment must be installed and operated in accordance with the instrucons con-
tained in this manual. Failure to do so could result in poor product performance, personal
injury and/or damage to your boat.
• Consult the boat manufacturer if you have any doubt about the strength or suitability of
the mounng locaon.
3.3 Electrical3.3 Electrical
• Make sure you have switched o the power before you start installing this product.
• This product requires installaon by a suitably qualied electrical engineer.
4.2 Accessories4.2 Accessories
Use only genuine Five Oceans parts and accessories to ensure top performance and eliminate
the risk of voiding your warranty. For replacement parts, please visit your dealer or
www.ve-oceans.com
4.3 Gypsy Suitability4.3 Gypsy Suitability
Gypsies ed to the Atlanc Horizontal windlasses are ideally suited to handling our factory
made Rope/Chain combinaon rodes, which consist of rope spliced to a chain tail. See 4.24.2
Specicaons for details.
Ropes used must be windlass grade, medium lay nylon. Ropes from dierent manufacturers
have wide variaons in stretch and consistency in diameter. Therefore, rope and chain from
othermanufacturers may require some experimentaon to determine the opmum size.
Should you have diculty in matching a gypsy to your chain please consult
info@ve-oceans.com.
4.4 Above deck preparaon4.4 Above deck preparaon
IMPORTANT - Plan locaon carefully and allow for the following:
4- Installaon4- Installaon
4.1 Basic requirements4.1 Basic requirements
Each installaon requires the following tools:
WINDLASS INSTALLATION
• An appropriate marine sealant
• Electric drill and 10mm (3/8”) drill bit
• 76mm (3”) Hole Saw
WIRING INSTALLATIONWIRING INSTALLATION
• Crimping Pliers / Wire Stripper
• Suitable electrical cable and crimp
terminals
25-60 mm
1" - 2 1/4"
21 3
