ENG | Installation and operating instructions
1. General
This manual is for Airx A expansion vessels with a capacity of 8 to 80 litres with a ow distributor
to be tted in a standard Airx A T-piece. The package includes an expansion vessel (A)
with label (B), a manual (C) and a ow distributor (D). See the label for the maximum working
pressure and the pre-charge.
When rinsing with additives (for instance for protection against legionella), the vessel has to be cut
off from the potable water installation, for example by means of an AirxControl.
Installation
• Expansion vessels with a capacity of 8 to 25 litres are installed hanging on the water nipple (E). If
necessary, use wall bracket MB 2/ MB 3.
• Expansion vessels with a capacity of 35 to 80 litres are installed hanging on the mounting eye (F),
with the water nipple (E) downward.
• If the expansion vessel is to work properly, a pressure-reducing valve must be tted immediately
behind the water meter.
Applications
• Use on the cold-water side of drinking water installations in combination with a type boiler
system.
• Use in pressurized systems.
• Any form of warranty or liability will be voided if used in any other way.
Safety requirements during installation
The expansion vessel comes pre-charged. Damage may result in serious injuries. The piping must
be able to carry a full expansion vessel.
Safety
• Prevent overpressure in the installation. Install a safety valve (for example Prescor B) or a safety
group in the boiler pipes to ensure this.
• Set the opening pressure of the safety valve to a value that is equal to or lower than the
maximum pressure shown on the label.
• The connection between the expansion vessel and the boiler must always be open.
2. Installation
The installation must be carried out by approved personnel only. Observe local regulations.
1. Slide the pieces of the ow distributor (D) approx. 58 mm apart.
2. Push the ow distributor (D) with the round cap into the T-piece (G).
3. Put PTFE tape (H) (do not use hemp!) on the expansion vessel connection.
4. Screw the expansion vessel onto the T-piece. This determines the length of the ow distributor.
5. For the purpose of annual maintenance, as prescribed, it is recommended that you install an
AirxControl module.
3. First use
1. Close the water supply (K) and drain the pressure from the boiler.
2. Adjust the pre-charge of the expansion vessel to a value of 0.2 bar lower than the minimum
cold-water pipe pressure. See the vessel label for the pre-charge.
• Remove the guard (L) and the plug (M).
• Measure the pressure (P).
• Push the inner valve (S) lightly if the pressure is too high.
