Flame TAKT - Page 22

22
In the RANGE submenu you can switch the LFO output to bipolar or unipolar.
The RANGE menu is the submenu of the Menu AMP.
Hold down the AMP button for about 1sec. When the button flashes, release it again. The
current setting is shown in the display. Change the value with the DATA knob.
Value range: bi / uni / Sid
bi bipolar output voltage range max. between -5V...+5V
uni unipolar output voltage range max. between 0V...+5V
Sid SideChain: inverted unipolar output +5V...0V
LFO - RANGE (voltage range)
+5v
-5v
0v
+5v
-5v
0v
“bi”=bipolar “uni”=unipolar
+5v
-5v
0v
“Sid”=Side Chain
unipolar-invers
