TAKT BASIC STRUCTURE
Essentially the module consists of two parts:
1. Sequencer (Looper)
8 tracks with two outputs per track for trigger/gate and CV (velocity or
modulation), as well as MIDI (note).
There are 5 patterns of 4 bars each available at the same time as a
“SCENE”. 50 scenes can be saved.
The resolution of the tracks is 96 ticks.
2. 4fold LFO
with separate outputs (bi- or unipolar), free-running, synced, or triggera-
ble by notes on a track.
The looper's tracks are recorded either by 8 track buttons on the device
or by four switchable external distance sensors or by received MIDI
notes.
There are analog inputs and outputs for CLOCK and RESET signals
respectively. There are also two programmable inputs USER 1+2 availa-
ble for connecting foot pedals or gate signals.
