6.3 DMX channel list
12CH mode
Channel
Function
Effect
CH 1
Pan
0-255: 0-630°
CH 2
Tilt
0-255: 0-270°
CH 3
Color wheel
0-17: No function
18-34: Color 1
35-51: Color 2
52-68: Color 3
69-85: Color 4
86-102: Color 5
103-119: Color 6
120-127: Color 7
128-192: clockwise rotation, fast to slow
193-255: Color wheel anticlockwise rotation, slow to fast
CH 4
Gobo wheel
0-17: No function
18-36: Gobo 1
37-55: Gobo 2
56-74: Gobo 3
75-93: Gobo 4
94-112: Gobo 5
113-127: Gobo 6
128-192: Gobo wheel clockwise rotation, fast to slow
193-255: Gobo wheel anticlockwise rotation, slow to fast
CH 5
Gobo wheel rotation
0: No function
1-127: anticlockwise rotation, fast to slow
128-255: clockwise rotation, slow to fast
CH 6
Strobe
0: No function
1-255: Strobe, slow to fast
CH 7
Dimmer
0-255: 0-100%
CH 8
Prism
0-12: No function
13-255: Prism
CH 9
Pan/Tilt speed
0-255: Fast to slow
CH10
Pan fine
0-255: Fine tune
CH11
Tilt fine
0-255: Fine tune
CH12
Reset
0-149: No function
150-200: Reset
201-255: No function
