FlashLogic FLRSGM7 - Page 5

U.S. Patent No. 8,856,780
www.flashlogic.comAutomotive Data Solutions Inc. © 2017 FLCGMRSGM7FLRSGM7EN
PAGE 5 OF 26
• 20170705
COMPATIBLE ACCESSORIES - 1 OF 1
FLRF1/2/4 RF KIT
RF KIT (accessories sold separately)
(NC)
ANTENNA
MODULE
RF PORT
FLHRNTM
TELEMATIC KIT (accessories sold separately)
(NC)
CARLINK
MODULE
TELEMATIC PORT
10 11 12 13 14 15 16
1 2 3 4 5 6 7 8
9
FLHRNTM
TELEMATIC KIT (accessories sold separately)
MODULE
TELEMATIC PORT
CAR CONNECTIONPN 4120260
OBDII CONNECTOR
VEHICLE
OBDII PORT
(NC)
DOC.: #40640
