FlashLogic FLRSGM7 - Page 6

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 1 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
BUICK
Encore Flip-Key AT 13-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
LaCrosse Flip-Key AT 10
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 LtBlue (-) BCM, left side of steering column ~
LaCrosse Flip-Key AT 11-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 LtGreen (-) BCM, left side of steering column ~
Regal Flip-Key
AT
*11
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Regal Flip-Key
AT
**11-
16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Verano Flip-Key AT 12-17
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
CHEVROLET
Camaro Flip-Key AT 10-15
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 LtBlue (-) BCM, left side of steering column ~
Colorado STD key
with Onstar AT
15-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Cruze / Cruze Limited
Flip-Key AT
10-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Equinox Flip-Key AT 10-17
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 LtBlue (-) BCM, left side of steering column ~
Impala / Impala Limited
Flip-Key AT
14-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 LtGreen/Gray (-) BCM, left side of steering column ~
Malibu Flip-Key AT 13-15
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green /Gray (-) BCM, left side of steering column ~
Malibu Limited STD Key 16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Gray (-) BCM, left side of steering column ~
Orlando Flip-Key AT 11-14
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Sonic Hatchback/Sedan
Flip-Key AT
12-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Spark
Flip-Key / STD Key AT
16-17
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light ~ Black 12 pin 03 Green/Gray (-) Light switch ~
Trax Flip-Key
AT
13-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
* Early production.
** Late production.
www.flashlogic.comAutomotive Data Solutions Inc. © 2017 FLCGMRSGM7FLRSGM7EN
PAGE 6 OF 26
• 20170705
DOC.: #40640
