FlashLogic FLRSGM7 - Page 7

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 2 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
GMC
Canyon STD Key
with OnStar AT
15-16
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
Terrain Flip-Key
AT
10-17
Swc ~ ~ 16 pin 01 Green (DATA) OBDII ~
Parking Light X1 White 26 pin 22 LtBlue (-) BCM, left side of steering column ~
* Early production.
** Late production.
