COMMISSIONING DYNAVERT L
4Bs0503en/002 Version: 11.10.02 16
1. Set the numeric value of the rated speed v3 exactly as great as the value for the positioning speed v Posi.
Perform a continuous travel with empty car, for this vary the adjustment in the motor the exact rated speed of the
motor in the menu item P-MOTOR DATA: Slipcomp in a way that the speed at the motor shaft is the same in up
and down direction.
• Check the adjustment using a speed meter!
2. In P-TRAVEL CURVE DATA:
− set v3 to the value of the rated speed.
− Brak.dist.3 = distance of the braking tag.
− Check-Up: Yes.
− press button .
3. Travel from both sides to all floors using command V3 nominal speed-normal travel, displace the stop switches in a
way that the car may stop flush.
HINT:
If the positioning travel is too short, or a jerking can be noticed in the car at the correction point, the measured
braking distances are shorter than the parameterized Brak.dist.3 (that means, the speed at the correction point
stop switch is too high). The measured braking distance is shown in the display with Brak.d.(S) = xxx.xx cm.
REMEDY:
- First of all increase the positioning distance Position. in P-TRAVEL CURVE DATA. If this action carries
no advance, see
Checking the braking distances
The measured braking distance is computed via counting the pulses regarding the system data (e.g. v/n-value).
Operating without pulse generator (actual value) the value is determined via the integration of the rated value
curve. According to the deviation from the actual rated value this method results in other values for the indicated
Brak.d.(S).
The actual (measured) braking distance should correspond centimeter exact to the parameterized braking
distance (P-TRAVEL CURVE DATA: Brak.dist.3).
The measured braking distance Brak.d.(S) must in any case not be shorter than the physical required minimum
braking distance from speed v3!
• Check the calculation of v/n from section 1.3.1, page 11, item 3!
• Adjust the braking tags in the shaft if the values for the measured braking distance Brak.d.(S) and the
parameterized distance Brak.dist.3 differ.
− If the differences are small (below 2 cm!) it is sufficient if travel curve with positioning has been selected to
parameterize the smallest measured braking distance (S) in P-TRAVEL CURVE DATA: Brak.dist.3!
Checking the correction point stop switch
The correction point stop switch should be located in the range of the constant positioning (see
Figure 3: Braking distances and travel curve designations)!
• do the normal travel using v3
• select menu item speed at the stop switch Speed (A) in the menu P-DRIVE DATA
− the indicated value should correspond to the traveled positioning speed v Posi (display: v-travel:=x.xx m/s), in
order to get the correcting access no to be remarked in the car (The positioning speed is automatically
lengthened or shortened).
If the displayed value is higher than the positioning speed traveled at the moment: increase the positioning
distance (P-TRAVEL CURVE DATA: Position.)!
4. If the positioning travel takes too much time increase the Brak.dist.3 in P-TRAVEL CURVE DATA, to reach
shorter positioning times.
