DD 2G 18.0-EC LD / PD 2G 18.0-EC LD
Technical data
Tool
DD 2G 18.0-
EC LD
PD 2G 18.0-
EC LD
Type Drill Driver
Percussion
Drill Driver
Rated
voltage
Vdc 18
No-load
speed
r.p.m 0-500 / 0-1800
Chuck
capacity
mm 1.5-13
Max. drill
diameter for
metal
mm 13 13
Max. drill
diameter for
wood
mm 52 52
Max. drill
diameter for
masonry
mm N/A 13
Torque, max.
– Soft screw-
driving
case
– Hard
screw-
driving
case
Nm
Nm
35
65
Impact rate bpm N/A
0-8000 /
0-28800
Clutch
settings
18+
24+
+
Weight
according
to”EPTA
Procedure
01/2003”
(without
battery)
kg 1.11 1.195
Battery
AP 18.0/2.5
AP 18.0/5.0
AP 18.0/8.0
Weight of
battery
kg
AP 18.0/2.5
AP 18.0/5.0
AP 18.0/8.0
0.4
0.7
1.1
Working
temperature
-10°-40°C
Storage
temperature
< 50℃
Charging
temperature
4~40°C
Charger CA 10.8/18.0, CA 18.0-LD
Overview (see figure A)
The numbering of the product features refers
to the illustration of the machine on the
graphics page.
1. Torque-adjustment ring
2. Keyless chuck
3. Chuck jaws
4. Variable-speed trigger switch
5. LED light
6. Two-speed gear shifter
7. Direction preselector switch (forward/
center-lock/reverse)
8. Soft grip
9. Strap fixing
For attaching a wrist strap (not included)
in order to reduce the chances of
dropping your tool.
10. Function-selection ring
Only for PD 2G 18.0-EC LD
11. Removable belt clip
12. Removable bit bracket
Operating instructions
WARNING!
Remove the battery before carrying out any
work on the power tool.
Before switching on the power tool
Unpack the cordless drill driver/hammer
drill and check that here are no missing or
damaged parts.
NOTE
The batteries are not fully charged on delivery.
Prior to initial operation, charge the batteries
fully. Refer to the charger operating manual.
Inserting/replacing the battery
Press the charged battery into the power tool
until it clicks into place (see figure B).
