Please check you have all the fi ttings listed below
M6x90mm Connecting bolt x8
Tools required
A
Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings
may be supplied than are required.
M6 Ø10x14mm Barrel nut x8
B
E
4,5x40mm Chipboard screw x4
C
10x45mm Dowel x22
D
Components - Fittings
Phillips
screwdriver
(medium)
Small
hammer
Ruler/tape
measure
4,0x30mm Chipboard screw x72
Allen key
4mm incl.
Flatblade
screwdriver
(medium)
6,3x50mm Assembly screw x8
F
No. 3909-63050
ø12x10mm Cover cap wood x3
G
No. 3939-00012-7
ø10mm Cover cap x10
H
No. 3938-00010-1
6,3x90mm Assembly screw x41
J
No. 3909-63090
ø7mm Cover cap x22
K
No. 3938-00007-1
4,5x60mm Chipboard screw x3
M
No. 3901-45060
ø10x88mm Connecting double bolt x4
N
No. 3934-10088
ø8mm Cover cap x8
L
No. 3938-000081-1
4
70x40,5x20mm Angle x2
O
No. 4008-022
No. 3901-45040
No. 3930-10045
No. 3901-40030
No. 3922-06014
No. 3913-06090
No. 4033-004
To Next Page
