Assembly Instructions
Step 1
Step 2
Insert dowels to
bedsides – and to all
the safety rails and .
It may be necessary to
tap the dowel in very
gently with a small
hammer.
Repeat same procedure
for all bedsids
10
and
all safety rails
12
and
14
Insert the connecting
double bolts to all the
short legs
Twist /turn the bolt to
follow the hole ø6,8 mm
Counter sunk 5 mm
hole should face same
direction as bedside
drilling
11
11
10
10
12
14
D
N
D
N
12
14
D
N
D
x2
x2
x4
Ø5 MM
Ø6,8 MM
Ø6,8 MM
N
bedside
drilling
