Flexit Silent Eco - Page 10

10
www.flexit.com
Ø 100 mm
Ø 110 mm
A B C D d2 E
Ø 100 mm 158 81 26 99 2 136
Ø 125 mm 182 91 27 124 2 158
Ø 125 mm
Ø 140 mm
Ø 100 mm Ø 125 mm
80 m³/h 170 m³/h
41 Pa 62 Pa
25 dB(A) 3 m 34 dB(A) 3 m
7,5 W 17 W
220-240V-50Hz 220-240V-50Hz
IP 45 IP 45
0
10
20
30
40
50
60
70
0 50 100 150
[Pa]
[m³/h]
100 mm
125 mm
D
A
BC
E
d2
