Flextherm FLK30 - Page 4

4
© 2016 OJ Electronics A/S
3
2
120 / 240 VAC
L2(N)L1(L)
LINE
1800W / 3600W MAX 15A
LOAD
14
BR1015A01b
© OJ Electronics A/S
Fig. 2
1
234
LOAD
1800W/3600W MAX 15A
LINE
120 / 240 VAC
L1(L)
L2(N)
WARNING
When fastening the screws
do NOT exceed a torque
greater than
1.2 Nm
WARNING
When loosening the screws
do NOT detach the screws
from the terminal.
ES: Advertencia
Al apretar los tornillos no
aplique un par de apriete
mayor que 1,2 N-m.
FR: Avertissement
Lors du serrage des
vis, ne pas excéder un
couple de 1,2 Nm.
ES: Advertencia
Al aflojar los tornillos, no
los separe completamente
del terminal.
FR: Avertissement
En desserrant les vis,
ne pas les enlever
des bornes.
Fig. 3
Udarbejdet af: Udarbejdet d.: 29.05.2015 Side 1 af 1
© 2015 OJ ELECTRONICS A/S • STENAGER 13B • DK-6400 SØNDERBORG
NTC 12kΩ @ 25°Celsius
°Celsius
°Fahrenheit
Ohm (Ω)
-10°C 14°F 55076Ω
0°C 32°F 34603Ω
10°C 50°F 22284Ω
20°C 68°F 14675Ω
30°C 86°F 9860Ω
Fig. 4
POWER MODULE THERMOSTAT
A B C D
OUT
SENSOR
IN / SENSOR
C
D
USG - 4000
BR1015A02b
A B C D
OUT IN / SENSOR
Fig. 5
BR1015A03a © 2015 OJ Electronics A/S
1
A B C D
OUT IN / SENSOR
1
2
2
UCG / UDG / UTN
Fig. 6
Fig. 1
BR1015A04a
BR1012C02a
© 2015 OJ Electronic A/S
BR1012C03a
© 2015 OJ Electronic A/S
BR1012C02a, BR1012C03a & BR1015A05 BR1015A02b
BR1015A01b
BR1015A03a
BR928A07b
