CHAPTER 76 – ENGINE CONTROLS
Contents
76-00.1 General
76-00.2 Description
76-00.3 Maintenance Practices
76-00.3.1 Throttle Box Inspection
76-00.1 General
This chapter provides description and information concerning maintenance of engine
controls.
76-00.2 Description
The throttle quadrant is located in the center pedestal, just behind the lower instrument
panel. It can be easily operated from both seats, although it is primarily designed to be
operated from the left seat, by the pilot-in-command.
Fig. 76-00-1
Pos. Description
1 Pitch trim control button.
2 Throttle lever.
3 Brake lever.
4 Parking brake valve.
